Overview Product Description KD-ZXJ Model Industrial Semi Auto 50Hz/60Hz Folder Gluer Carton Box Pasting Machine Carton
SHARE
Send inquiry

Description

Overview
Basic Info.
Model NO. KD-ZXJ
Feeding Way Vacuum Suction Paper Feeding
Usage Folding and Gluing Carton Box
Voltage 220V/380V/440V/as Requested
Core Components PLC, Engine, Motor, Pump
Transport Package Wrapped in PE Film or Cotton Cloth, Then Packed by
Specification Depends on paper size
Trademark KADING
Origin Dongguang, Cangzhou, Hebei
HS Code 84393000
Production Capacity 100sets/Year
Product Description

Kd-Zxj Model Industrial Semi Auto 50Hz/60Hz Folder Gluer Carton Box Pasting Machine Carton Box Folding Gluing Machine Folder Gluer

Kd-Zxj Model Industrial Semi Auto 50Hz/60Hz Folder Gluer Carton Box Pasting Machine Carton Box Folding Gluing Machine Folder Gluer

Product Description

KD-ZXJ Model Industrial Semi Auto 50Hz/60Hz Folder Gluer Carton Box Pasting Machine Carton Box Folding Gluing Machine Folder Gluer

WorkbenchPhotoelectric control of paper loading height, reducing labor intensity and improving work efficiencyFlatting Correction1. After the glue is applied, it is flattened twice to make the adhesion both smooth and firm.2. Equipped with an automatic correction device to make the carton have the correct size and effectively avoid the phenomenon of knives and forks at the bonding part (notch)3. Fan air drying function.4. The counting output device is equipped with a photoelectric counter-setting mechanism, and when the number of cartons reaches a certain number, it will automatically outputHorizontal OutputThe horizontal output will automatically work after receiving and counting the output signal, and the stacking is convenient and difficult.Other Main Components1. The gear reducer adopts domestic famous brand.2. The electrical part adopts Chint brand.3. The output belt adopts the honored product of Sibeck.4. The whole group of paste head is precision processed with imported materials, which is wear-resistant, corrosion-resistant and easy to clean.

Product Parameters

Product Name
Max.size (length+width) (mm)2800
Min.size (length+width) (mm)340
Max.size (width+height) (mm)1515
Min.size (width+height) (mm)250
Paper feed height (mm)900
Motor power (kw)2.3
Machine weight (kg)2000
Working speed (pcs/min)40
Dimension (L*W*H) (mm)5500x1800x2000

Kd-Zxj Model Industrial Semi Auto 50Hz/60Hz Folder Gluer Carton Box Pasting Machine Carton Box Folding Gluing Machine Folder Gluer

Detailed Photos

Kd-Zxj Model Industrial Semi Auto 50Hz/60Hz Folder Gluer Carton Box Pasting Machine Carton Box Folding Gluing Machine Folder Gluer

Cangzhou Kading Carton Machinery Manufacturing Co.,Ltd was founded in 2004 and is located in Dongguang County, Cangzhou City, Hebei Province. We are a manufacturing enterprise that produces carton making machinery.Our company's self-produced product lines include carton printing machines, carton die-cutting machines, and carton slotting machines; our advantageous products include Carton stitching machines, Folder gluer machines, Flute laminating machines, Single facer machines, etc.After nearly twenty years of sales and production experience, our product supply chain is already very mature, so we can help customers one-stop purchasing.In addition to our own foreign trade business, our factory also cooperates with many trading companies, so our products are exported to dozens of countries such as the Middle East, Africa, Southeast Asia, and the European Union, and are well received by the majority. There are also many brand&branded manufacturers among our customers. You are welcome to cooperate with us~!

Kd-Zxj Model Industrial Semi Auto 50Hz/60Hz Folder Gluer Carton Box Pasting Machine Carton Box Folding Gluing Machine Folder Gluer


Q: Are you a factory or a trading company?
A: We are a direct manufacturer that is located in Dongguang county, Cangzhou city. Welcome to visit our factory! We can also have video call if you'd like an online factory tour
Q: How do you ensure your quality?
A: 1. Trustworthy and long-term cooperative raw material suppliers;2. Skilled&experienced engineer&workers;3. Mature QC system;4. Specially-assigned merchandiser;5. Advanced production workshop
Q: How about your after-sale service?
A: 1. Special after-sale team will be 24/7 online;2. Can guide the installation door-to-door;3. One-year warranty for spare parts.
